VEHICLE HARNESS
LIFT HARNESS
VEHICLE HARNESS
LIFT HARNESS
Tu rn COUNTER -
CLOCKWISE
to LOWER platform.
Tu rn CLOCKWISE
to RAISE platform.
8
SECTION 1 : OWNER
Operating Your Lift
Figure 8-1
Figure 10-2
Figure 8-2
MANUAL OVERRIDE
IMPORTANT!
You MUST unplug the two-connector plug BEFORE
any attempt to use the Manual Override. Failure to
do so result in serious injury.
WARNING
Disconnect power from lift
BEFORE attempting manual
override.
1. Unplug Power to the Lift.
[Figure 8-1]
2. Remove the cap on top of the motor.
[Figure 8-2]
3. Insert a 3/8” socket wrench into the
actuator and rotate the Hex Shaft. [Figure 8-3]
Figure 8-3
In the event of a power failure, for example
if your car battery dies, your lift can still
operate using the Manual Override system.
4. Turn COUNTER-CLOCKWISE to LOWER
the platform. [Figure 8-4]
5. Turn CLOCKWISE to RAISE the platform.
[Figure 8-4]
Figure 8-4
| www.harmar.com | 800-833-0478
