7
SECTION 1 : OWNER
Operating Your Lift
CLOSING THE SWING AWAY
Close the Swing-Away unit as you would a
car door.
WARNING
Stay clear of the latching
mechanism
Figure 7-1
SAFELY CLOSED
WRONG
SAFELY CLOSED
WRONG
Figure 7-2
Figure 7-3
WARNING
Always install the safety pin.
CAUTION
Verify that the T handle has
fully retracted.
AL350 Hitch-Mounted Scooter and Power Chair Lift
Figure 7-4
P/N: 610-00065 Rev A
