Harmar Mobility AL625 - Default Chapter; Table of Contents

AL625 Page 2
REV: 1-24-12
TABLE OF CONTENT
SECTION TITLE PAGE #
REQUIREMENTS AND CONSIDERATIONS BEFORE INSTALLATION ……………………………………3
SAFETY FIRST …………………………………………………………………………………………………….4
TOOLS AND SUPPLIES REQUIRED FOR INSTALLATION ……………………………………………………. 4
STEP 1 ELECTRICAL WIRING 5
STEP 2 INSTALLING THE MOUNTING BARS 6
• MOUNTING THE TRACKER DIRECTLY TO THE VEHICLE’S FLOOR 7
STEP 3
POSITION THE TROLLEY ASSEMBLY ON THE MOUNTING BARS 8
STEP 4 ATTACH LEVELING FEET TO THE TROLLEY ASSEMBLY 9
STEP 5 POSITION THE TROLLEY ASSEMBLY AND BOLT IT DOWN 10
STEP 6 RAISE THE BOOM AND INSTALL THE BOLT 11&12
STEP 7
MOUNTING THE PLATFORM ASSEMBLY TO THE TROLLEY ASSEMBLY 13
STEP 8 CHECK CLEARANCES WITHOUT LOAD 14
STEP 9 ADJUST PLATFORM ANGLE TO SUIT LOAD (if necessary) 15
STEP 10
ADJUSTING THE VERTICAL – HORIZONTAL TRANSITION (if necessary) 16
STEP 11
CONFIRMING HOME POSITION AND LOCKING PIN ALIGNMENT 17
STEP 12 INSTALLING THE STRAP SYSTEM 18-19
FUSE FOR RF REMOTE CONTROL CIRCUIT ………………………..………………………………………… 20
TRAINING THE END-USER ……………………………………………………………………………………… 20
MAINTAINING THE LIFT ……………………………………………………………………………………….. 20
TROUBLESHOOTING ……………………………………………………………………………………………. 21
ELECTRONIC CONTROL BOX WIRING DIAGRAM ...…………………………..……………………………. 22
FOR YOUR RECORDS
SALESPERSON______________________________________
TELEPHONE________________________________________
PURCHASE DATE_________________________________LIFT SERIAL #______________________________________
CUSTOMER #_____________________________________ORDER #___________________________________________
