HIGHLANDER II VERTICAL PLATFORM LIFTS: Install Manual
17FEB2021 | 630-00113 REV C
21
INSTALLATION
HIGHLANDER II: SECTION 4
Reset the board
❑ Enter service mode by pressing and
releasing the service button
❑ Press and hold down the service
button again for 3-seconds.
❑ Press and release the reset button.
FINAL INSTALLATION
Completing the above steps will clear any errors
from the board.
1.
panel should rest on the pins in the tower.
at the top front panel leaving the top three (3)
2. Disconnect the power to the lift. Connect
the cable in the top cap for status indicator
lights into the control board. Slide the top
cap over the top of the tower aligning the top
cap slots with the four (4) side screws and
three (3) front screws. There are tabs in the
back of the top cap that drop into slots in the
tower top plate. These tabs must drop into the
slots for the top cap to sit down on all seven
(7) screws. Tighten seven (7) ¼"-20 screws
securely against the top cap. Reconnect the
power to the lift.
OPERATIONAL CHECK
Upon installation and at scheduled intervals the
operation of the VPL must be verified.
NOTE: ASME A18.1-2017 requires that when the lift is
installed in commercial applications, operation checks
are to be conducted not less than weekly by authorized
personnel.
Apply power and verify all four (4) LED
indicator lights are solid green.
Paddle/buttons on cab controls control UP
and DOWN travel.
E-Stop PRESSED IN stops and prevents travel
of platform. Button illuminates and alarm
sounds (if equipped). Indicator lights 1, 2, 3
and four (4) are solid RED.
Key switch (if equipped) OFF stops and
prevents travel.
Landing switches stop the platform at each
opens the gate locks.
Automatic Door Openers (if equipped) open
the doors/gates at landing.
Open doors/gates prevent any travel of the
(4) are solid RED.
Call Station buttons control UP and DOWN
travel.
Key switch (if equipped) OFF on Call Stations
stops and prevents travel from Call Station.
Safety pan switches depressed prevent
DOWN travel and allow UP travel (check
several locations). Indicator lights one (1)
and (2) are flashing AMBER.
Pit switch (if equipped) prevents UP and
DOWN travel. Indicator lights 1, 2, and 3 are
solid RED
