Harmony V7 - Installing Locking Clip

24

A locking clip is used to prevent certain vehicle
seat belts from loosening before a sudden stop
or crash. The locking clip can  be used on
a vehicle lap/shoulder belt. A locking clip will
not x all types of vehicle seat belt problems.
If your vehicle’s 3-point lap/shoulder seat belt is
equipped with an Emergency Locking Retractor (ELR)
that is  converble to funcon as an Automac
Locking Retractor (ALR), then the locking clip  be
used.
If you have any quesons about the specic type of seat
belt system in your vehicle and/or its operaon, consult
your vehicle owner’s manual.
• Remove the locking clip from mesh storage pocket on
restraint backrest (see “Parts list”, pg. 17-19).
• Follow the steps to properly secure vehicle lap/
shoulder seat belt (see “Installing with Lap/Shoulder
or Lap-only belt system”, pg. 32).
• Once seat belt is aached and properly adjusted, grasp
the two straps (lap and shoulder) together as close to
the vehicle belt buckle plate as possible. Unbuckle the
belt without allowing it to slip.
• Aach the locking clip around both lap and shoulder
belts (as shown).
• Posion the locking clip about
2.5 cm (1 inch) from vehicle belt’s
buckle plate.
• Rebuckle belt. Check that the lap
belt does not move by pulling hard.
If belt loosens or lengthens, repeat the procedure.
Test installaon to see if child restraint is secure. The
child restraint should  be able to move in any
direcon where is connects to the vehicle. If the child
2.5cm (1”)
