container) or a plate cut from the outer casing must
be placed under the container to prevent excessive
heat radiation from the stove.
The package includes more detailed installation
instructions.
3.8. Changing the opening direction of the
stove door
The door to the firing chamber can be installed to
open either to the right or to the left. Both sides of
the firing chamber opening have holes for the hinge
pin. Open the door and remove the hinge pin by
lifting it up so that it clears the lower holes of the
door and frame. Then tilt the pin slightly to the side
pull it downwards past the lower holes and out of
the upper ones.
Turn the door to open in the desired direction and
place the pin back in. Hold the detached door open
near the heating chamber opening. Check that the
holes of the hinge pin align at the top edge of the
door and push the hinge pin through the top holes
upwards from the bottom. Align the holes at the
bottom edge of the door as well, and drop the hinge
pin through the bottom holes to its position. The
hinge pin will stay on top of the bottom holes by
means of a spreader that is compressed in the pin.
See figure 15.
dem Behälter ein (mit dem Behälter mitgelieferter)
zusätzlicher Schutz oder eine aus dem Außenmantel
geschnittene Platte angebracht werden, um eine zu
starke Hitzeabstrahlung des Ofens zu vermeiden.
D i e P a c k u n g e n t h ä l t a u s f ü h r l i c h e r e
Montageanweisungen.
3.8. Änderung der Öffnungsrichtung der
Ofentür
Dir Ofentür kann so montiert werden, dass sie
entweder nach links oder nach rechts zu öffnen
ist. An beiden Seiten der Heizöffnung befinden sich
Löcher für den Scharnierstift. Öffnen Sie die Tür
und entfernen Sie den Scharnierstift, indem Sie ihn
so weit anheben, dass die unteren Löcher der Tür
und des Rahmens frei sind. Kippen Sie den Stift
dann leicht zur Seite, ziehen Sie ihn nach unten in
Richtung der unteren Löcher und schließlich aus den
oberen Löchern heraus.
Drehen Sie die Tür so, dass sie in die gewünschte
Richtung zeigt, und stecken Sie den Stift wieder
ein. Halten Sie die gelöste Tür offen neben der
Heizöffnung. Achten Sie darauf, dass die Löcher
des Scharnierstiftes am oberen Rand der Tür sich
übereinander platzieren, und schieben Sie den
Scharnierstift durch die oberen Löcher von unten
aus nach oben. Führen Sie auch am unteren Rand
der Tür die Löcher übereinander und lassen Sie den
Scharnierstift durch die unteren Löcher in Position
fallen. Der Scharnierstift bleibt auf der am Stift
gepressten Verbreiterung an den untersten Löchern
hängen. Siehe Abbildung 15.
