Press the transmitter button within 10 seconds.
Correct programming will be signaled by the LED
blinking three times. 2 blinks indicate full memory.
1 blink means the end of the learning time.
After correct programming, we have another 10s
to program the other transmitters, etc.
To finish the procedure, wait 10 seconds from the
last programming or shortly press the LEARN
button. LED will blink and the receiver will return
to normal operation.
TECHNICAL SPECIFICATION
400Y
Supply voltage AC 230V 50Hz
Motor power 160 W
Engine speed 1400 rpm
Travel speed 12 m/min.
Output torque 10 Nm
Gate weight do 600 kg
Noise level < 62 dB
Auto-closing time 5s-10min
Continuous operation time max. 120s
Control board HEL11:8.2.2
Standby power consumption < 4,5 VA
Remote control type: E Keeloq version HP-001* (1 piece)
Remote control operating frequency 433,92 MHz (with rolling code)
Min. Range of the remote control in open area 30 m
Remote control battery type Typ 23A 12V
Memory of transmitters 28 pcs
Fuse type 5A/230V, ø5x20
Operating temperature range -40 ; +70
Dimensions (length x height x width) 263 mm x 215 mm x 270 mm
* the manufacturer reserves the right to change the remote control attached to the drive set
DECLARATION OF CONFORMITY
The HATO 400Y drive meets the requirements of the following regulations:
Complies with the conditions of the Machinery Directive 2006/42 / EC Annex II Section B as amended.
Complies with the conditions of the following EU directives:
Directive on electromagnetic compatibility EMC 2014/30 / EU
Low Voltage Directive LVD 2014/35 / EU
The following harmonized standards have been applied:
