• Simple installation and programming procedure.
MODE OF ACTION
The drive is controlled by the transmitter button programmed in HELB11 or the SBS
sequence control bell button. In the case of control from the SBS input or a transmitter assigned to
this function, the operation consists in carrying out the step-by-step commands OPEN-STOP-
CLOSE-STOP or with the ONLY OPEN function enabled, it is only possible to open the gate. After
turning on the power, the first command is to open, if we give the next command while the gate is
moving, we will stop it, and then we can run it in the closing direction. The WICKET function
(partial opening) is controlled by a button on the transmitter assigned to this function.
Depending on the version, the controller works with motors with or without a built-in
pulser. For the version with the pulse generator, it is also possible to disable its support during
the engine operation programming procedure. The lighting of the ENCODER diode means that
the operation is switched on.
ATTENTION!
The pulser parameters must be consistent with the description in paragraph SOFTWARE for the
appropriate version of the controller.
DRIVER INSTALLATION
Before starting the installation, make sure that all safety
recommendations are met.
Any installation work may only be performed by qualified personnel.
Electrical installation and connection of electronic devices may only be
performed by persons with appropriate electrical qualifications.
1. Turn off the power.
2. Install the controller mechanically.
3. Pull out the quick couplings.
4. Connect the cables to the quick couplers according to the description or connection diagram:
(wires connected to quick couplers should be flexible - "cord")
1.1. Connecting the limit switch for opening and closing
The limit switch for opening and closing is used to precisely stop the gate in the closed or open
position. Adjust the position of the magnets so that the gate opens and closes accurately.
16 OL —opening limit
17 CL — closing limit switch,
18 COM — common cord
The controller works with the normally open NO or normally closed NC type limit switches. The
selection is made with the NC / NO switch.
NC/NO from position ON –normally open NO
NC/NO in position OFF –normally closed NC
1.2. Connecting photocells
The infrared barrier is an essential security element that must be connected to the
controller. It prevents the gate from hitting a vehicle, person or object in its light. Photocells are
