necessary for the correct operation of the device and ensure safety. If the encoder support is
disabled, it is required to connect a safety curtain or other additional protection against crushing
in the gate's light. They must be connected in series with the photocells
.
PHOTOCELL
12 +24VDC – photocells power supply plus
13 COM –photocells power supply minus
13 COM –COM output of the photocell
14 FOTO –NC contact of the photocell
The power supply of the 24V connector is <450mA, therefore make sure
that the total power load does not exceed this current value. An exemplary
photocell connection diagram is shown in fig. 2.
1.3. Connection of the manual control
Connection of the manual control should be made with a 2x 0.5mm cable (the cable type
should be in accordance with CEI 20-22; CEI EN50267-2-1 standards), the maximum length of the
manual control cable depends on its electrical parameters, therefore it should be assumed the
following rule that with the required cable length, its resistance should not exceed 100ohm. As a
standard, the use of a cable with a cross-section of 0.5 mm and a length of not more than 20 m is
sufficient for the correct operation of the controller, for required greater distances, 4x0.5 (mm)
cables can be used by connecting the wires in parallel - in pairs, or by increasing the cross-section
of the cable (2x 1mm).
15 SBS –bell button
18 COM
1.4. Pulse generator connection - OPTIONAL
The controller supporting the pulser located on the engine has an ENCODER connector. The
installation consists in connecting the wires to this connector.
Next, make the electrical connections of the connector on the left side as shown
in Fig. 2.
1.5. Capacitor connection
Connect a capacitor to connector numbers 9 and 10, polarity does not matter.
1.6. Motor connection
The motor connection should be made in accordance with the description:
7 COM – common engine wire
11 OPEN – motor cable to activate it in the direction of opening
8 CLOSE – motor cable to actuate it in the closing direction
1 PE – PE protective conductor
1.7. Connection of signal lighting
The light bulb with a power not exceeding 15W / 230V should be connected to connectors 5 and 6:
5 – the neutral wire of the lamp
6 – lamp phase wire
When using the flashing light function, do not connect the signaling
device with the built-in internal circuit breaker. This can damage the driver.
When using a signaling device with a built-in circuit breaker, make sure that the
light function is set to continuous mode before connecting it.
Fluorescent lamps must not be used as traffic lights.
1.8. Power connection
