4.1.3. Other controls
Mirror adjustment
4.2. Instruments and controls, more detail
4.2.1. Clutch
4.2.1.1. Clutch pedal (1)
The clutch pedal is used for operating the clutch between
the engine and the gearbox.
NOTE: Never rest your foot on the clutch pedal while
driving. Do not allow the clutch to slip more than necessary
when starting.
IMPORTANT: The engine can only be started when the
clutch pedal is fully depressed (even if the gear lever is in
neutral).
4.2.1.2. Clutch lever, power take off (2)
NOTE: With this lever (2) the disengagement can be done
only temporarily (max. 5 min..) When PTO has been
disengaged with this lever the indicator light lights up on the
instrument panel.
1
2
