Dimensions & weights (mm, kg)
Traktör
A70 / A70L 2WD
A70 / A70L 4WD
A80 / A80L 2WD
A80 / A80L 4WD
A90 4WD/ A100 4WD
/
A110 4WD
Tires rear
460/85R34 460/85R34 460/85R34
Tires front
7.50-20 / 380/85R24 7.50-20 / 380/85R24 380/85R34
Length
4141 / 4231 4141 / 4231 4141 / 4231
Total width(mm-16,9-30)
2137 2137 2137
Total Height
2605 2605 2605
Grounnd clearance (rear hook)
500 / 490 500 / 490 500 / 490
Wheelbase(4WD)
2100 / 2200 2100 / 2200 2200 / 2300
Total Weight(kg)
3120 / 3330 3120 / 3330 3740
Front axle 4X2/4X4 width
1420 / 1610
1515 /1730
1420 / 1610
1515 /1730
1410 / 1610
1515 /1730
Rear axle width
1508-1708 1508-1708 1508-1708
Permissible Axle Loadings
MODEL
Loading capacities for All A series
tractors
Rear Axle
3800 kg
2WD Front Axle
1500 kg
4WD Front Axle
2430 kg
Tightening torques, wheel nuts
- Front Wheels, 2WD…………………….130Nm
- Front Wheels, 4WD…………………….300Nm
- Rear Wheels... ………………………….550Nm
- Wheel discs, front and rear……... ……310 Nm
Track widths, mm
REAR AXLE
STANDARD
TRACK WIDHT
FRONT AXLE
STANDARD
TRACK WIDHT
460/85R34 1508 - 1708 7.50-20 1420 -1610
380/85R24 1515 - 1730
380/85R24 1420 -1610
When track widths are adjusted or larger Tires fitted, the turning angles have to be checked/adjusted with max
turning angle of front axle on both sides. When adjusting the rear axle track widths, check that the wheels
rotate freely. Check when using chains that the distance from the cab to the Tires is not less than 80 mm.
Check further that the distance from parking lights to the outer sides of the Tires does not exceed 400 mm.
Wheel nuts, tightening torque
- The front wheels, 2WD ……………………….. 130 Nm
- the front wheels, 4WD ………………………… 300 Nm
- the rear wheels ………………………………… 550 Nm
- Wheel-wheel disc , Front and Rear …………. 310 Nm
