Hatz 1B30 Operator's Manual

Safety 1B20, 1B27, 1B30, 1B40, 1B50
10
HATZ
Operator's Manual
Signal words
Signal words identify the magnitude of the risk and the seriousness of the
possible injuries:
Danger symbol/
signal word
Meaning
DANGER
This signal word is used to indicate imminently
dangerous situations which, if not avoided, will
lead to serious injury or death.
WARNING
This signal word is used to indicate potentially
dangerous situations which, if not avoided, may
lead to serious injury or death.
CAUTION
This signal word is used to indicate potentially
dangerous situations which, if not avoided, may
lead to minor or moderate injury.
CAUTION
This signal word, without a danger symbol, is
used to indicate the risk of property damage.
NOTICE
This signal word indicates additional useful infor-
mation, such as operating tips and cross refer-
ences.
3.1.4 Meaning of safety symbols
Explanation of symbols
The following table describes the meanings of the safety symbols used in
this Operator's Manual.
Symbol Meaning
Smoking, fire, and open flames are prohibited!
Warning of personal injury!
Warning of hot surfaces!
Warning of flammable substances!

Hatz 1B30 Specifications

General

Compression Ratio	20.5:1
Fuel System	Direct injection
Lubrication System	Forced lubrication with gear pump
Engine Type	Single-cylinder, four-stroke, air-cooled diesel engine
Power Output	5.7 kW at 3000 rpm
Starting System	Recoil starter
