Hatz 1B30 Operator's Manual

General information 1B20, 1B27, 1B30, 1B40, 1B50
6
HATZ
Operator's Manual
2 General information
Information on the document
This Operator's Manual was created with due care. It is exclusively intended
to offer a technical description of the machine and to provide instructions on
commissioning, operating and maintaining the machine. When operating the
machine, the applicable standards and legal regulations as well as any in-
house regulations apply.
Before commissioning, during operation and before maintenance work is be-
gun on the machine, read the Operator's Manual carefully and keep it close
by for ready access.
Machine
This Operator's Manual describes the following machine.
Machine name HATZ diesel engine
Type number 1B20, 1B27, 1B30, 1B40, 1B50
Customer service
Have service work performed by qualified technicians only. We recommend
that you work with one of the over 500 HATZ service stations. Trained spe-
cialists there will repair your machine with Hatz original spare parts and
with HATZ tools. The global HATZ service network is at your disposal to ad-
vise you and supply you with spare parts. For the address of the Hatz ser-
vice station nearest you, please see the directory included or visit the inter-
net at: www.hatz-diesel.com
Problems may occur if unsuitable spare parts have been installed. We can-
not accept responsibility for damage and secondary damage that result from
this.
We therefore recommend the use of genuine Hatz original spare parts.
These parts are manufactured according to strict Hatz specifications and
achieve maximum operational reliability through their perfect fit and function-
ality. The order number can be found in the enclosed spare parts list or on
the internet at: www.hatz-diesel.com
Exclusion of liability
The manufacturer cannot be held responsible for personal injury, damage to
property, or damage to the machine itself caused by improper use, foresee-
able misuse, or failure to follow or adequately follow the safety measures
and procedures described in this Operators Manual. This also applies to
changes made to the machine and the use of unsuitable spare parts.
Modifications, which serve technical improvement, are reserved.

Hatz 1B30 Specifications

General

Compression Ratio	20.5:1
Fuel System	Direct injection
Lubrication System	Forced lubrication with gear pump
Engine Type	Single-cylinder, four-stroke, air-cooled diesel engine
Power Output	5.7 kW at 3000 rpm
Starting System	Recoil starter
