1.241.24
MAINTENANCE
Refer to the Maintenance Schedule at the end of this section
and ensure that the recommendations are followed. More
frequent service is required when operating in adverse con-
ditions.
AIR CLEANER SERVICE
- Gain access to the cartridge (3) by loosening screw
(1) and tilting cover (2).
- Replace the cartridge if very dirty or damaged.
- Clean the cartridge by tapping gently on a flat sur-
face. Do not use petroleum solvents during cleaning
as this will cause the cartridge to deteriorate. Do not
use pressurised air as this may damage the cartridge.
Do not oil the cartridge.
- After servicing the cartridge re-install it in the cover.
Insert the tabs on the bottom of the cover into the slots
in the bottom of the base (4). Tilt the cover upwards
and securely tighten the screw to the base.
1. Screw
2. Cover
3. Cartridge
4. Base.
Remove grass debris from the grassbag immediately after
use and check its condition for signs of damage.
WARNING - PREVENT ACCIDENTS: Replace a dam-
aged grassbag immediately.
Remove grass debris from the top and underside of the deck
housing immediately after use.
IMPORTANT - PREVENT DAMAGE: Fertilisers and
top dressings are particularly corrosive. Thoroughly
clean the mower deck immediately after use on treated
grass and store well away from corrosive materials.
GRASSBAG
DECK HOUSING
