Engine will not turn over
Engine stop lever released
Operate engine stop lever
Incorrect oil level
Check oil level
Obstruction under deck
Remove obstruction
Engine smokes
Excess oil level
Check oil level
Air cleaner cartridge oil
Service air cleaner
soaked or plugged
Engine runs then stops
Fuel starvation
Fill fuel tank
Fuel cap vent blocked
Clean fuel cap vent
F
AUL
T
FINDING
39701
1MA260599A
32
34
Table of Contents
Default Chapter
3
Table of Contents
3
Introduction
5
Warranty
6
Safety Precautions
8
Decals
10
Specifications
11
Assembly Instructions. 1.10
12
General Assembly
12
Assembling the Mower for the First Time
13
Starting the Engine. 1.13
15
Before Starting the Engine. 1.13
15
To Start the Engine
16
Stopping the Engine
17
Operating the Mower. 1.16
18
Height of Cut
18
Travel
19
Turning the Mower
19
Mowing with Grass Collection
20
Mowing Without Grass Collection
21
Heavy Growth
21
Moving the Mower Across Non-Grassed Areas
21
Cutterbar Operation
22
Mowing and Grass Care Tips
22
Maintenance
24
Engine
24
Oil Service
25
Air Cleaner Service
26
Grassbag
26
Deck Housing
26
Securing Nuts and Bolts
27
Lubrication
27
Speed Change Cable
27
Clutch Cable Adjustment
28
Cutterbar 1.26
29
Maintenance Schedule 1.28
30
After First 5 Hours
30
Every 5 Hours or Daily
30
Every 25 Hours or Every Season
30
Every 50 Hours or Every Season
31
Every 100 Hours or Every Season
31
Preparing the Mower for Storage
32
Fault Finding
33
397 S Parts List Diagram.
40
398S Parts List Diagram
40
399S Parts List Diagram
41
Engine Ancillary Parts
42
Engine Warranty
43
Notes
44
