MAINTENANCE
SPEED CHANGE CABLE (Code 399S only)
LUBRICATION
Lubricate the wheels, pivot points and linkages with engine
oil every 25 operating hours.
Apply a good quality medium grease to the inner control
cables at the point of entry and exit from their outer casings.
SECURING NUTS AND BOLTS
Regularly check that all securing nuts and bolts are tight.
Replace missing or damaged items immediately.
If the speed difference between the settings on the speed
change control are judged to be too little or do not exist at all
it may be necessary to adjust the cable.
1. Run the mower in the position for a few minutes.
2. If there is any play in the cable by nipple Y the cable must
be adjusted. Loosen the locking nut X and adjust the cable by
screwing out the nipple Y until the play on the cable is taken
up.
3. Tighten the locking nut X.
Note! Do not tension the cable more than necessary, it should
just sit in the nipple Y without play. Too much cable tension
will cause the drive belt to break or result in damage to other
parts of the transmission. When adjusting after maintenance
(e.g. fitting a new belt) always start with the nipple Y screwed
in fully.
397011MA260599A
