Hayward Goldline Controls Aqua Logic AQL-P-4 User Manual

12
This menu will appear only if the Lights are configured for timeclock. The lights will turn on
and off at the designated times. The only override on this function is manual on/off control
by the “Lights” button.
This menu will appear only if the Lights are configured for countdown timer. This setting is
the time after you manually turn on the lights until the Aqua Logic automatically turns off the
lights. You can also manually turn off the lights at an earlier time by pressing the LIGHTS
button. If the Lights relay is on during the programmed off time, it may be because of freeze
protection.
Aux1 and Aux2 configurations are identical.
This menu will appear only if the Aux1 is configured for timeclock. The Aux output will turn
on and off at the designated times. If the Aux relay is off during the programmed on time—
note that some pool equipment (example pressure side pool cleaner) can only be operated
when the filter pump is running and the pool/spa valves are in the pool-only position—the
Aqua Logic will keep the relay off until these other conditions are suitable for operation. If
the Aux relay is on during the programmed off time, it may be because of freeze protection.
Also, manual operation overrides the timeclock.
This menu will appear only if the Aux1 is configured for countdown timer. This setting is the
time after you manually turn on the Aux relay until the Aqua Logic automatically turns off the
relay. You can also manually turn off the relay at an earlier time by pressing the AUX1 button.
Set Day and Time
Wednesday 10:37P
+
>
>
Adjust time setting
Move between start and stop times & to previous/next menu item
Lights-all
8:00P to 11:00P
+
>
>
Adjust time s
Lights-wkend
8:00P to 11:00P
Lights-wkday
8:00P to 11:00P
+
+
>
>
>
>
Adjust time setting
Adjust time setting
Move between start and stop times & to previous/next menu item
Move between start and stop times & to previous/next menu item
or
or
Lights-CountDn
0:20
+
>
>
Adjust time setting (Manual On/Off, 0:05, 0:10, 0:15...)
Move to previous/next menu item
Set Day and Time
Wednesday 10:37P
+
>
>
Adjust time setting
Move between start and stop times & to previous/next menu item
Aux1-all
8:30A to 4:00P
+
>
>
Adjust time s
Aux1-wkend
8:30A to 4:00P
Aux1-wkday
8:30A to 4:00P
+
+
>
>
>
>
Adjust time setting
Adjust time setting
Move between start and stop times & to previous/next menu item
Move between start and stop times & to previous/next menu item
or
or
Aux1-CountDn
0:20
+
>
>
Adjust time setting (Manual On/Off, 0:05, 0:10, 0:15...)
Move to previous/next menu item
