50’, 100’, 200’
PANEL CONNECTING
CABLES OPTIONAL
7
SYSTEM OVERVIEW
MAIN CONTROL CENTER
MASTER CONTROL PANEL
SPA SIDE CONTROL PANEL
INPUT SENSORS VALVE ACTUATORS
AIR TEMP
SENSOR
LOW VOLTAGE CONNECTIONS
EQUIPMENT OUTPUT CONNECTIONS
LINE NEUTRAL LUG NEUTRAL FOR 120V EQUIPMENT
BONDING LUGS FOR EQUIPMENT
WATER
TEMP
SENSOR
25’ CABLE
TWO SUPPLIED WITH POOL/SPA SERIES
SENSOR
MOUNT
MASTER CONTROL CABLE
Spa-side panels are available
on certain systems and have
100’ or 200’ cables.
GROUND LUGS
LOW VOLTAGE RACEWAYS
POWER INPUT LUGS
GFCI
10’ CABLE10’ CABLE
PSC2038
MOUNTING
CLIP
INTEGRATED
40 AMP
EXPANDER BOARD
-Can be wired for 120 VAC or
240 VAC, 2 wire plus ground
-Can be wired for 120 VAC and
240 VAC, 2 wire plus ground
ITEM #-PSC2004
CIRCUIT BREAKER
WITH ENCLOSURE
50 A MAX. GFCI
ITEM #-PSC2021
