Operating Instructions
Radio Transmitter eco
Page 20 / 24 AOEM1G30 [PMTS/DOKUS]
HBC-radiomatic GmbH • 74564 Crailsheim • Germany
2007-06-18 Information and specifications subject to change without notice.
Radio Control System
5 Technical Data
eco
Unique system address over 1,000,000 combinations
Transmitting power TC/TX 641: < 10 mW
Frequency range
433 ~435 MHz
Channel increments 25 MHz
Transmitter antenna internal
Operating temperature range –25 °C ... +70 °C (-13 °F … +158 °F)
Housing material impact-resistant ABS plastic
Housing color orange
Dimensions 202 x 88 x 176 mm (8.0 x 3.5 x 6.9 “)
Protection class IP 65
Max. number of control commands 32 digital + 8 prop. + STOP
Battery type BA2250_0
Power supply 6 V / 1500 mAh
Operating time at 100% duty cycle ca. 20 hours
Weight ca. 1,5 kg (3.3 lb.)
