Structure and mode of operation
C9C A03729_03_YI0_01 HBM: public 13
Fig. 4.1 The underside of the transducer is fitted with a thin metal plate to protect the
strain gages
In versions with nominal (rated) forces up to 200 N, there is also a metal plate
on the top of the transducer, that also needs to be handled with care.
