HBM C9C User Manual

Dimensions
26 A03729_03_YI0_01 HBM: public C9C
8 Dimensions
SW9
SW9
Nominal (rated) force
50kN
X
Nominal (rated) force
50N…200N
Nominal (rated) force
0.5kN…20kN
Min. bending
radius R10
X
ØG
ØG
U
R
T
B
0.3
ØA
10.5
Ø3
5
18
ØG
SW9
J
H
15°
3x120°
U
R
B
T
ØA
5
18
10.5
J
H
Ø3
3x120°
4x90°
45°
Min. bending
radius R10
Dimensions in mm
Fig. 8.1 Dimensions of C9C
Nominal (rated) force
of C9C
A
-0.1
B G
+/-0.1
H J R T U
-0.1
X
[mm]
50N - 200N 26 15 20.5 3 x M3 6 20 2.5 5.5 10.5
0.5 kN - 20 kN 26 13 22.75 3 x M2 3.5 40 1 8 10.5
50 kN 46 28 40 4 x M4 6 80 8 16 10.5
