9.1 Versions and ordering numbers
Code Measurement
range
Ordering number
0050 50N 1C9C/50N
0100 100N 1C9C/100N
0200 200N 1C9C/200N
00K5 0.5kN 1C9C/0.5KN
01k0 1kN 1C9C/1KN
02k0 2kN 1C9C/2kN
05k0 5kN 1C9C/5kN
10k0 10kN 1C9C/10kN
20k0 20kN 1C9C/20KN
50k0 50kN 1C9C/50KN
Cable
length
Electrical connection Transducer
identification
1.5m
01m5
Free ends
Y
With TEDS chip
T
3m
03m0
15-pin Sub-D connector
F
Without TEDS chip
S
5m
05m0
Male connector MS3106PEMV
N
6m
06m0
15-pin Sub-HD connector
Q
7m
07m0
With inline amplifier 0…10 V
VA1
12m
12m0
With inline amplifier 4…20 mA
VA2
KC9C- 05k0 12m0- F- T
All cable lengths can be combined with all plugs.
Information
TEDS can only be ordered in conjunction with a plug option. It is not possible
to combine TEDS and free cable ends.
Versions with inline amplifiers (VA1 and VA2) can only be combined with cable
lengths 1.5 m and 2 m; TEDS is not available for these measurement chains.
The ordering number example
K-C9C-05k0-12m0-F-T shown further
below refers to a C9C, 5kN nominal
(rated) force with 12m cable, 15-pin
Sub-D connector and TEDS.
