Operation
K148 A01681_03_X00_04 HBM: public 17
Ground
+V
IN
1
2
3
4‐pin connector, mini DIN
*)
4
21
43
USBHBM1264
*)
SELV circuit
(safety extra-low voltage)
Fig. 5.5 12 V DC IN connector pin assignment
5.2 Front panel of the device
Range steps / calibration steps
Channel selection
Polarity
% step
Measuring range
