28
PME-MP30DP
HBM A0737-4.0 de/en/fr
5 Operation via the keyboard
During measurement you can press
+
−
− to view the status messages in
the display (e.g. mV; V; Out,In; error messages).
Next to the status message “ERROR” the display shows the status of the
Profibus DP connection. One of the following status messages is displayed in
each case:
BD_SEAR (baud rate search)
WT_PARM (waiting for parameter)
WT_CONF (waiting for configuration)
DATA_EX (cyclical data traffic)
ERROR (bus error)
The LED shows the operating status (ready to take measurements, overflow
etc.) of the MP30DP. Instead of the CAN status, however, the Profibus status
is displayed (as is the case with the PM30).
Operating status:
LED
colour
Status Meaning
Profibus status
Green Steady light DATA_EX status
Yellow Steady light BD_SEAR, WT_PARM, WT_CONF status
Red Steady light ERROR status
The representation of the other operating statuses is the same as that of the
MP30.
