The targeted operation of the required control bits in the control word allows
you to secure all the functions not required against accidental operation in the
event of an error; otherwise, for example, the zero point set could be lost.
If you are using older parameter assignment tools the parameter values will
have to be converted to decimal or hexadecimal values:
Octet Bit
s
Parameter name Available values Default Meaning
0 0..
7
reserved 0 0 do not change
1)
1−2 all Diagnosis 0 = disabled
0xffff = enabled
enabled Operation of external
diagnosis
3 all Data format 0 = integer 16 bits
1 = integer 32 bits
2 = Floating Point
Integer 16
bits
Defines the coding
format for measured
values
4 0−
1
Parameter set
control bits
0 = disabled
3 = enabled
locked operates function for
control of output
control word
5 0 Zeroing control
bit
0 = disabled
1 = enabled
locked operates function for
control of output
control word
5 1 Taring control bit 0 = disabled
1 = enabled
locked operates function for
control of output
control word
5 4 Control bit
Delete
maximum
0 = disabled
1 = enabled
locked operates function for
control of output
control word
5 5 Control bit
Delete minimum
0 = disabled
1 = enabled
locked operates function for
control of output
control word
5 6 Control bit
Hold maximum
0 = disabled
1 = enabled
locked operates function for
control of output
control word
5 7 Control bit
Hold minimum
0 = disabled
1 = enabled
locked operates function for
control of output
control word
5 2 Autocal
control bit
0 = disabled
1 = enabled
locked enables function for
autocalibration with
the aid of output
control word
Tab 6.10: Contents of the parameter assignment message
1)
changed by your parameter assignment tool in certain circumstances
