HBM MP30DP - Outputs (from the PLC to MP55 IBS)

35
PME-MP30DP
HBMA0737-4.0 de/en/fr
Status1
Bits Name Meaning
0 MeasVOvfl Measured values overflow
1 AOutOvfl analog output overflow
2 ScalErr Scaling defective
3 EEPROMErr EEPROM (parameter set) defective
4 Limit1 Status of limit switch 1
5 Limit2 Status of limit switch 2
6 Limit3 Status of limit switch 3
7 Limit4 Status of limit switch 4
8 PAR1 Active parameter set bit 1
9 PAR2 Active parameter set bit 2
10..14 res reserved
15 MViO Measured value in order
1)
(if bit 0,2,3=0)
Tab 6.13: Contents of status 1
1)
Meaning of MViO:
NOR operation of: MesswOvfl, SkalErr, EEPROMErr.
MesswOvfl is the OR operation of ADCOvfl, HardwOvfl, GrossOvfl, NetOvfl
The parameter set number is coded in 2 bit binary:
Bit 8 Bit 9 Parameter set no.
0 0 1
1 0 2
0 1 3
1 1 4
Status 2
Double status word 2 returns detailed error flagging.
Bits Name Meaning
0 HardwOvfl Hardware overflow
1 ADCOvfl ADC overflow
2 GrossOvfl Gross signal overflow
3 NetOvfl Net signal overflow
4 AOutOvfl Analog output overflow
5 MaxOvfl Maximum overflow
6 MinOvfl Minimum overflow
7 NegOvfl Overflow in negative direction
8 Limit1 Status of limit switch 1
9 Limit2 Status of limit switch 2
10 Limit3 Status of limit switch 3
11 Limit4 Status of limit switch 4
12 SkalInError Scaling input invalid
13 SkalOutError Scaling output invalid
14 GainError Nominal value exceeded
15 Init.Error Works calibration defective
16 TransducerError Transducer error
21 Stand Still standstill recognition
22..31 res reserved
Tab 6.14: Contents of status 2
