6.2 Configuration
The configuration defines which data content is exchanged in the cyclical data
communication. The following data is available for selection:
Input values:
Name Meaning Length
Gross gross measured value 1 or 2
words
Net net measured value (gross minus tare value) 1 or 2
words
Max contents of the maximum store 1 or 2
words
Min contents of the minimum store 1 or 2
words
Pk−Pk peak−to−peak, difference between max and min 1 or 2
words
Status1 status word with status of the limit switches and gen. error
bits
1 word
Status2 double status word with differentiated error flagging 2 words
Output values:
Name Meaning Length
Control word control word for triggering taring, zeroing, clearing the peak
value store, parameter set selection, etc.
1 word
Limit1 level at which limit switch 1 responds 1 or 2
words
Limit2 level at which limit switch 2 responds 1 or 2
words
Limit3 level at which limit switch 3 responds 1 or 2
words
Limit4 level at which limit switch 4 responds 1 or 2
words
The formats of the cyclically communicated data content are specified in detail
in chapter 6.3. The measured values are offered optionally as a 16-bit integer,
32-bit integer or 32 bit float. The values are always scaled to physical size
with the number of decimal places of your choice. Information on whether the
16 bit format or a 32 bit format is used and on the number of decimal places is
defined in the parameter assignment message.
Typical combinations are predefined in the GSD file. If you require other
combinations you can expand the GSD file accordingly using the following
specifications.
