HBM MP60DP - Page 17

17
PME−MP60DP
HBMA0623-6.1 en/de/fr
Status 1
Bits Name Meaning
0 Ovfl measured values overflow
1 AOutOvfl analogue output overflow
2 ScalErr scaling defective
3 EEPROMErr EEPROM (parameter set) defective
4 Limit1 status of limit switch 1
5 Limit2 status of limit switch 2
6 Limit3 status of limit switch 3
7 Limit4 status of limit switch 4
8 PAR1 active parameter set bit 1
9 PAR2 active parameter set bit 1
10..14 res reserved
15 MViO Measured value in order
1)
(if bit 0,2,3=0)
Tab 6.5: Contents of status 1
1)
Meaning of MViO:
NOR operation of: MesswOvfl, SkalErr, EEPROMErr.
MesswOvfl is the OR operation of ADCOvfl, HardwOvfl, GrossOvfl, NetOvfl
The parameter set number is coded in 2 bit binary:
Bit 8 Bit 9 Parameter set no.
0 0 1
1 0 2
0 1 3
1 1 4
Status 2
Double status word 2 returns detailed error flagging.
Bits Name Meaning
0 HardwOvfl hardware overflow
1 ADCOvfl ADC overflow
2 GrossOvfl gross signal overflow
3 NetOvfl net signal overflow
4 AOutOvfl analogue output overflow
5 MaxOvfl maximum overflow
6 MinOvfl minimum overflow
7 NegOvfl overflow in negative direction
8 Limit1 status of limit switch 1
9 Limit2 status of limit switch 2
10 Limit3 status of limit switch 3
11 Limit4 status of limit switch 4
12 ScalInError scaling input invalid
13 ScalOutError scaling output invalid
14 GainError nominal value exceeded
15 InitError works calibration defective
16 TransducerError transducer error
17..31 res reserved
Tab 6.6: Contents of status 2
