Mechanical installation
28 A3452-10.0 T40B
3. Fasten all screws with the specified torque (Tab. 5.1
on page 29).
4. There are six or eight tapped holes on the rotor for
continuing the shaft train mounting. Again use screws
of property class 10.9 or 12.9 and tighten them with
the prescribed torque, as specified in Tab. 5.1.
Important
Use a threadlocker (medium strength, e.g. LOCTITE) to
glue the screws into the counter thread to exclude pre
stressing loss due to screw slackening, in the event of
alternating loads.
Note
Comply with the maximum thread reach as per Tab. 5.1.
Otherwise significant measurement errors may result
from torque shunt, or the transducer may be damaged.
Measuring range Fastening screws Prescribed tightening
moment
NVm Z
1
Property class NVm
50 M8 10.9 34
100 M8 10.9 34
200 M8 10.9 34
500 M10 10.9 67
1 k M10 10.9 67
2 k M12 10.9 115
3 k M12 12.9 135
