Specifications
T40B A3452-10.0 59
Nominal (rated) torque M
nom
50020010050NVm
Temperature effect per 10 K in the
nominal (rated) temperature range
on the output signal, related to the
actual value of the signal span
Frequency output % "0.1 "0.05
Voltage output % "0.4 "0.2
on the zero signal, related to the
nominal (rated) sensitivity
Frequency output % "0.1 "0.05
Voltage output % "0.2 "0.1
Nominal (rated) sensitivity
(span between torque = zero and
nominal (rated) torque)
Frequency output 10kHz / 60kHz /
240kHz
kHz 5/30/120
Voltage output V 10
Sensitivity tolerance
(deviation of the actual output quantity
at M
nom
from the nominal (rated)
sensitivity)
Frequency output % "0.1
Voltage output % "0.1
Output signal at torque = zero
Frequency output kHz 10/60/240
Voltage output V 0
Nominal (rated) output signal
Frequency output
with positive nominal (rated)
torque
kHz 15
1)
/ 90
2)
/ 360
3)
(5 V symmetri
cal
4)
)
with negative nominal (rated)
torque
kHz 5
1)
/ 30
2)
/ 120
3)
(5 V symmetrical
4)
)
Voltage output
