HBM T40B - Torque Specs (1 kN·m - 10 kN·m)

Specifications
64 A3452-10.0 T40B
Nominal (rated) torque M
nom
50020010050NVm
Breaking torque, related to M
nom
15)
% 800 > 400
Longitudinal limit force
16)
kN 5 5 10 13
Lateral limit force
16)
kN 1 1 2 4
Limit bending moment
16)
N⋅m 50 50 100 200
Oscillation width per DIN 50100
(peak‐to‐peak)
17)
N⋅m 200 200 400 1000
Mechanical values
Torsional stiffness c
T
kN⋅m/rad 180 180 360 745
Torsion angle at M
nom
degrees 0.016 0.032 0.032 0.038
Stiffness in the axial direction c
a
kN/mm 285 285 540 450
Stiffness in the radial direction c
r
kN/mm 160 160 315 560
Stiffness during the bending
moment round a radial axis c
b
kN⋅m/deg. 1.9 1.9 3.6 4.2
Maximum deflection at longitudinal
limit force
mm <0.04 <0.05
Additional max. radial deviation at
lateral limit force
mm <0.02
Additional plumb/parallel deviation
at limit bending moment (at j d
B
)
mm <0.06 <0.11
Balance quality level per
DIN ISO 1940
G 2.5
Max. limits for relative shaft
vibration (peak‐to‐peak)
18)
Undulations in connection flange
area, based on ISO 7919-3
Normal operation (continuous
operation)
μm
s
(p*p)
+
9000
n
Ǹ
(n in rpm)
Start and stop operation/resonance
ranges (temporary)
μm
s
(p*p)
+
13200
n
Ǹ
(n in rpm)
Mass moment of inertia of the
rotor J
v
