Specifications
T40B A3452-10.0 73
Nominal (rated) torque M
nom
105321kNVm
Limit torque, related to
M
nom
34
% 200 160
Breaking torque, related to
M
nom
34
% > 400 > 320
Longitudinal limit force
35)
kN 19 30 35 60 80
Lateral limit force
35)
kN 5 9 10 12 18
Limit bending moment
35)
N⋅m 220 560 600 800 1200
Oscillation width per
DIN 50100 (peak‐to‐peak)
36)
N⋅m 2000 4000 4800 8000 16000
Mechanical values
Torsional stiffness c
T
kN⋅m/
rad
1165 2515 3210 5565 14335
Torsion angle at M
nom
degrees 0.049 0.046 0.054 0.051 0.040
Stiffness in the axial
direction c
a
kN/mm 580 540 570 760 960
Stiffness in the radial
direction c
r
kN/mm 860 1365 1680 2080 2940
Stiffness during the bending
moment round a radial
axis c
b
kN⋅m/deg. 5.9 9 9.3 20.2 45.5
Maximum deflection at
longitudinal limit force
mm < 0.05 < 0.06 < 0.08 < 0.09
Additional max. radial
deviation at lateral limit force
mm < 0.02
Additional plumb/parallel
deviation at limit bending
moment (at j d
B
)
mm < 0.09 < 0.18 < 0.19 < 0.14 < 0.12
Balance quality level per
DIN ISO 1940
G 2.5
