Disclaimer: 3
rd
party and/or custom firmware providing extra features are not covered in this manual.
Highlight Hardware Features:
Vertex² Exclusive: 4×2 Matrix/Splitter/Scaler for 4K HDR/DV 18Gbps/600MHz + Full HDMI Audio out
(extract HDMI/ARC/eARC)
Vertex² central is featuring 4 HDMI inputs, 2 HDMI video output with scaling option and 1 dedicated
HDMI full audio output at 720p or 1080p, LAN Control, RS232, L/R stereo or Optical 5.1 output, IR RX, IR
sensor, IR window, OLED display and 4 buttons on the side allowing to enter/exit and perform change in
the device system menu. Vertex² offers an unique and exclusive output management to accommodate
Android TV and such sink devices that perform annoying check in standby mode.
All inputs are capable of 4K HDR/HLG/DV/LLDV/HDR10+ up to 18Gbps for video and support any sound
format in existence today, HDMI TX0 and TX1 video outputs are capable of outputting 18Gbps and all
sound formats as well.
Vertex² is always running in a Matrix/Scaler mode ensuring your setup remains optimized at its best
capabilities
4×2 Splitter/Switcher/Scaler up to 4K60 4:4:4 600MHz 18Gbps + HDMI audio out
Splitting any signal up to 4K60 4:4:4 600MHz signal is now a reality, thanks to IR/RS232/push buttons or
Webserver, you can easily switch between 4 inputs that will be replicated up to 2 outputs for video and
3 outputs for audio (one UHD / one UHD/FHD + HDMI Audio out). HDCP conversion and scaling rules are
auto configured and applied on the fly in order to always output the type of video signal and HDCP
encryption that your display or sink device is expecting.
4×2 Matrix up to 4K60 4:4:4 600MHz 18Gbps + HDMI audio out
Matrix solution is available for HDMI stream up to 4K60 4:4:4 8b, 4K60 4:2:2 12b, 4K120 4:2:0 8b or
8K30 4:2:0 8b. Process two 18Gbps signals at the same time from 2 sources to 2 sinks devices and have
one of the channel duplicated and converted in res/hdcp/chroma/color depth/color space/etc to 1080p
+ a third output with HDMI audio out.
