Disclaimer: 3
rd
party and/or custom firmware providing extra features are not covered in this manual.
Main Specifications
4x Input / 2x Output Splitter/Matrix/Scaler + Audio out (HDMI2.0b/HDMI1.4/DVI1.0 compatible)
■ 4K60 4:4:4 600MHz 18Gbps Pass through
■ 4K24/25/30/50/60 <> 1080p24/25/30/50/60 Upscale/Downscale with or without colordepth
maintained and with or without chroma conversion.
■ Video Bandwidth - 18 GBP/sec.
■ HDR10+/Dolby Vision Support.
■ 4K 10, 12, 16 Bit Support
■ 16 Bit Per Pixel Deep Color Depth Available (48 Bit)
■ Max Res: 4K60 4:4:4 8b, 4K60 4:2:2 12b, 4K120 4:2:0 8b or 8K30 4:2:0 8b
■ Signal Conversion: Resolution, Chroma Subsampling, Color Space, Color Depth, HDCP
HDCP Doctor (HDCP Workaround solution to any HDCP error)
■ HDCP 2.2 > HDCP 1.4 conversion
■ HDCP 1.4 > HDCP 2.2 conversion
■ HDCP x.x > HDCP x.x conversion
■ Dual HDMI2.0b & HDMI 1.4 combined
■ Dual HDCP 1.4 & HDCP 2.2 combined
CEC Support: For inter-device control between both inputs and the primary output TX0 HDMI channel.
OLED infoscreen and OSD to provide useful and insight view of signal information
Audio Extracting: Audio De-Embedder of Optical & Analog L/R
Advanced EDID management via IR, IP, RS232 or Webserver
■ Improved EDID Management solution with either a Selected EDID bank, Custom uploaded EDID, Self-
generated Automix EDID or a Fixed basic EDID.
■ Sniff EDID from connected sink devices, Save, Edit, Load any custom EDID table at any time.
■ Select and pick any EDID of your choice from a preloaded list of EDID tables, it loads and reset HPD to
present your chosen one automatically.
■ AutoMix EDID feature will create a custom EDID by mixing both sink EDID connected to the splitter
output ports.
■ Some EDID flags can be forced in Automix such as: Stereo/5.1/Full/YCbCr/BT2020/HDR/3D
■ Each input can run a specific/individual EDID.
Infoframe Modes: Capture, edit, block or replace HDR metadata, AVI & VSIF.
Read SPD, Audio, HDMI Vendor, HDMI Forum
Control Modes: IR, IP, RS232 or Webserver for Linux/MAC/Win/Android/iOS.
HDMI Booster/Extender: Capable of extending 1080p resolution up to 15m. in and 15m. out (30m.
total for 1080p), UHD resolution up to 10m.
HDMI Doctor: Solves most HDMI integration issues such as HDCP, EDID, HPD, and audio breakout.
