[AUTOSWITCH INPUTS]: When activated, the new TMDS / Pixel clock Auto switch feature will force the
Vertex² unit to automatically switch to the active signal if the selected signal is lost. It can also auto
switch source that keep sending +5V when in standby such as ATV4K, X1X, Shield and others.
[AUTOSWITCH PRIORITY]: When input priority mode is enabled, as soon as a new active input is
detected, Vertex² will switch to it.
[HDCP VERSION]: Allow you to select/force the HDCP revision of the TX1 Output Port.
[HTPC MODE]: Useful if you have trouble with windows display and icons when resuming from stand-by
mode. Please note that with default firmware HTPC mode is not compatible with HDCP signal. You can
set HTPC mode for each input individually.
[OLED DISPLAY]: Enabled by default, Vertex² OLED display can be turned ON/OFF at will. Some users
might found the Vertex² OLED display visually disturbing in their HT setup. You have the possibility to
turn it off.
[ROTATE 180 DEG]: OFF by default, based on your setup, you might prefer to flip the OLED display, once
activated, this option will flip the Vertex² OLED.
[REVERSE COLORS]: OFF by default, once activated this option will reverse the Vertex² OLED colors.
[OLED FADE]: Allow you to define a custom timing in seconds before OLED FADE, set it to 0 for OLED to
always stay active. Default is 30sec.
[OLED PAGE]: Select the OLED page that will be displayed at startup .
[MUTE TX0 AUDIO]: If you use an AVR at HDMI audio out, you might want to disable sound going to
equipment connected at TX0 output. Here you can mute the TX0 output sound.
[MUTE TX1 AUDIO]: If you use an AVR at HDMI audio out, you might want to disable sound going to
equipment connected at TX1 output. Here you can mute the TX1 output sound.
[IR]: You can globally turn ON or OFF IR support for Vertex²
[ANALOG L/R AUDIO CONTROL]: This option will adjust the Analog Stereo output from this section.
Volume, Bass and Treble control are available.
[SEND]: After Volume, Bass or Treble values changes, click send to apply your changes.
[TEST PATTERN GENERATOR FOR TX0]: Once configured with dropdown field and enabled, this option
will display a test pattern at TX0 output. It can be useful for testing equipment. 480p60, 720p60;
1080p60, 4k24 or 4K60 resolution are available, Pattern can be color bars, ramp1 or ramp2 and HDCP
can be set to none, 1.4 or 2.2
[IP CONFIG]: This section allows you to edit the way Vertex² will retrieve its IP address. Any changes will
only be applied after reboot (power cycle)
