Maximum total draw =19,9mA with red led diodes mute
on
19.2.7 OUTPUT - Line Output via Jack: Nominal 0.5v
RMS @ 150 Ohms Mix of Ch.1 & Ch.2 + Aux IN via
Mono Jack Socket. (Standard ¼" / 6.35mm Diam.)
D.I Balanced Output via XLR Adapter: Nominal 0.5v RMS
@ 150 Ohms Electronically Balanced (Mono)
XLR IN/Out Wiring: Pin 1 = Earth/Ground, Pin 2 =
+Signal (Plus), Pin 3 = - Signal (Minus)
Noise Level (True RMS 20 Hz-20 kHz) At/@ 20 dB gain,
EDB-2 H.E produces (-)90 dB. At /@10 dB gain, EDB—2
H.E produces -94 dB Distortion: THD
See 6.1 Noise Notes
19.2.8 POWER SUPPLY UNIT - D.C Adapter
Supplied as standard - Mains Plug type & PSU inclusion
with EDB-2 H.E determined by Trade Purchaser
AC ADAPTER: CE in EU, UL Listed in USA. PSE in
Japan
INPUT: 100-240VAC 50/60 Hz @ 100mA+ OUTPUT:
18VDC @ 0.5A+ N.B. Output power can be higher
than 100mA without problems as power is drawn from
PSU
Input Plug Connections (L.P.S.): 2.1mm Diam. Outer =
+VE (Positive)• Inner = - VE (Negative)
P.59
