Page
21
(
)-
Connect
a
2-1/2"
brown
wire
from
lug
B
of
transistor
socket
Q10
(NS)
to
hole
E
in
the
circuit
board
(S-1).
( )
Connect
a
2-1/2"
brown
wire
from
lug
B
of
transistor
socket
Q9
(NS)
to
hole
B
in
the
circuit
board
(S-1).
Y
Connect
a
1-1/2"
black
wire
from
lug
C
of
transistor
socket
Q9
(S-1) to
solder
tab
J
(NS).
(
,)
Connect
a
2"
yellow
wire
from
lug
E
of
transistor
socket
Q9
(S-1) to
hole
C
in
the
circuit
board
(S-1).
( )
Connect
a
1-1/2"
black
wire
from
lug
3
of
terminal
strip
G
(NS) to
solder
tab
J
(NS).
)
Connect
a
2"
yellow
wire
from
lug
E
of
transistor
socket
Q10
(S-1)
to
hole
D
in
the
circuit
board
(S-1).
G--)--eonnect
a
2"
red
wire
from
lug
C
of
tran-
sistor
socket
Q10
(S-1)
to
hole
F
in
the
circuit
board
(S-1).
)
Connect
a
6"
red
wire
from
hole
G
in
the
circuit
board
(S-1)
to
lug
2
of
terminal
strip
G
(NS).
( )
Install
the
1N3754
diode
(#56-33)
in
diode
mounting
clip
K
with
the
color
dot
toward
transistor
socket Q9,
as
shown.
(
Place
1"
of
sleeving
on
the
diode lead
nearest
the
color
dot;
then
connect
this
lead
to
lug
B
of
transistor
socket
Q9
(S-2).
()-
-
Place
1"
of
sleeving
on
the
other diode
lead;
then
connect
this
lead
to
lug
B
of
tran-
sistor
socket
Q10
(S-2).
Connect
a
.01
p.fd
1.4
KV
disc
capacitor
between
lugs
1
(S-2)
and
2
(S-1)
of
terminal
strip
H.
Place
a
1"
length
of
sleeving
on
one
lead
of
a
110
s2
5
watt
resistor;
then
connect
this
lead
to
lug
5
of
terminal
strip
G
(NS).
Connect
the
other
lead
of
this
resistor
to
lug
1
of
terminal
strip
G
(S-2).
Position
the
body
of
the
resistor
down
against
the
chassis.
GY
-
Connect
a
3"
red
wire
from
lug
5
of
terminal
strip
G
(NS)
to
lug
2
of
circuit
breaker
C
(S-1).
Refer
to
the inset
drawing
on
Pictorial
11
for the
following
steps.
V')
Refer
to
Detail
11G,
and
identify
the
cathode
lead
of
a
silicon
diode.
Then
connect
the
cathode
lead
to
lug
5
(NS)
and
the
other
lead
to
lug
3
(NS)
of
terminal
strip
G.
NOTE:
WHEN
INSTALLING
DIODES.
BE
SURE
TO
PLACE
THE
CATHODE
END
AS
DIRECTED.
THE
CATHODE
END
IS
MARKED
WITH
EITHER
A
COLOR
END.COLOR
DOT.
COLOR
BAND.
OR
A
SYMBOL.
SYMBOL
COLOR COLOR
COLOR
(CATHODE
DOT
BAND
END
ENDI
Detail
11G
(
).
Connect
the
cathode
lead
of
a
silicon
diode
to
lug
4
(NS)
and
the
other
lead
to
lug
3
(S-4) of
terminal
strip
G.
(7
-Y
.-
Connect
the
cathode
lead
of
a
silicon
diode
to
lug
2
(NS)
and
the
other
lead
to
lug
5
(S-4) of
terminal
strip
G.
)
Connect
the
cathode
lead
of
a
silicon
diode
to
lug
2
(S-4)
and
the
other
lead
to
lug
4
(S-3)
of
terminal
strip
G.
( )
Hold
a
23"
large
red
wire
and
a
22"
large
black
wire
even
at
one
end.
Then
tie
a
knot
in
the
two
wires
15-1/2"
from
the
even
end.
At
the
uneven
end
of
this
pair
of
wires,
con-
nect
the
large
black
wire
to
solder
tab
J
(S-4).
Route
the
large
red
wire
under
the
wires
connected
between
the
circuit
board
and
transistor
sockets,
and
connect
the
large
red
wire
to
hole
A
in
the
circuit
board
)
Pass
the
free
end
of
this
pair
of
wires
through
grommet
D.
