Heatilator A36C - Fireplace Setup; Gas Log;Lighter Provision; Wood Burning Inserts

Heatilator • A36/42C, A36/42CH • Installers Manual • 4017-262 • Rev D • 10/07/13
34
B. Wood Burning Inserts
WARNING! Risk of Fire! Improper installation of wood in-
sertsmaycausereplaceorchimneysystemtooverheat.
Ifawoodburninginsertisbeinginstalledinthisreplace,
Hearth&HomeTechnologiesrecommendsfullrelineof
thechimney.
• DO NOTcoverinletoroutletgrills.
• Coolingairopeningsatthetopofthechimneymustnot
beobstructedinanymanner.
• Hearth&HomeTechnologiesrecommendssecuringthe
relineatthetopoftheueandusingthecapcertiedfor
usewiththisreplacesystem.
Firebox
Repack
insulation
knockout
Combustible
materials
Maintain air clearance
to combustibles.
Gas line
Combustible materials
may be located at zero
clearance to gas line
beyond 4 in. (102 mm)
from fireplace side.
Gas line
1 1/2 in. (38 mm)
air space around
pipe
Refractory
Seal with
fireplace mortar
or non-combust-
ible sealant
4 in.
(102 mm)
Outer shell
of fireplace
Figure 8.1 Gas Line Installation
A. Gas Log/Lighter Provision
WARNING! Fire and/or Asphyxiation Risk! Use with
solidwoodfuelordecorativegasapplianceonly.Gasre
generates fumes.
• DO NOT install unvented gas logs
• Dampermustbelockedfullyopenwhengaslogsare
installed
Acertiedgasloglighterordecorativegaslogsetcanbe
installedinthisreplace.
• Maximuminputis100,000BTU/hr.
• Decorative gas appliance must be certied to ANSI
Z21.60 “Standard for Decorative GasAppliances for
InstallationinVentedFireplaces”.
• MustbeinstalledinaccordancewiththeNational Fuel
Gas Code, ANSI Z223.1.
• Agaslogsetmustincorporateagasshutoff.
• GasLogsetrequiresthedampertobelockedfullyopen.
• Alistedautomaticdampersystemwithsafetyinterlock
may be used in this replace with only compatible,
listedgaslogsets.Seedampersystemmanufacturer’s
instructions.
• Knockoutsareprovidedonbothsidesofthereplace
andinrefractoriesfor1/2in.(13mm)ironpipe.
• Sealrefractoryaroundpipe with replace mortar ora
non-combustiblesealant.
8
Fireplace Setup
