Heatilator A36C - Page 37

Heatilator • A36/42C, A36/42CH • Installers Manual • 4017-262 • Rev D • 10/07/13
37
TR344 Round Termination Cap
TR342 Round Telescoping Termination Cap
ST375 Square Termination Cap
TS345/TS345P Square Termination Cap
15-3/4 in.
(400 mm)
34-3/4 in.
(883 mm)
32-1/2 in.
(826 mm)
23 in.
(584 mm)
19 in.
(483 mm)
15-5/8 in.
(397 mm)
13 1/4 in.
(337 mm)
18 in.
(457 mm)
16 1/4 in.
(413 mm)
26 1/2 in.
(673 mm)
28 5/8 in.
(727 mm)
TCT375 Terra Cotta Cap
22 1/2 in.
(572 mm)
9 1/2 in.
(241 mm)
16 1/2 in.
(419 mm)
9 1/2 in.
(241 mm)
