- 24 -
Service Call 0844 736 9138, Technical Help (Chargeable) Call 0906 802 0253
12 Speci ed Adjustment
12.1 Heating circuit adjustment
By pass operation is automatic and not adjustable.
If necessary,  t an external by-pass.
HEATING // 35W V1 / bypass closed
HEATING //35W V2/ bypass closed
HEATING //35W V2 / bypass middle position
HEATING //35W V2 / bypass opened
HEATING // 35W V1 / bypass closed
HEATING //35W V2/ bypass closed
HEATING //35W V2 / bypass middle position
HEATING //35W V2 / bypass opened
KEY
KEY
CaprizPlus 24 : 25kW
0.0
1.0
2.0
3.0
4.0
5.0
6.0
0
100
200
300
400
500
600
700
800
900
1000
1100
1200
1300
1400
1500
0
100
200
300
400
500
600
700
800
900
1000
1100
1200
1300
1400
1500
Water Flow in L/hr
Available pressure in mCE
CaprizPlus 28 : 30KW
0.0
1.0
2.0
3.0
4.0
5.0
6.0
Water Flow in L/hr
Available pressure in mCE
