HEIDENHAIN Programming Station TNC 320/TNC 620/TNC 640 13
1.2 Compatibility
Differences in fixed cycles
Fixed cycles of the iTNC 530, TNC 426/TNC 430, TNC 310 and
TNC 410 controls
Meaning of the symbols used in the table:
– Parameter not available in this software version
þ Parameter or cycle available in this software version
x Cycle not available in this software version
Cycle
Additional
parameters
iTNC 530
TNC 426/
TNC 430
TNC 310 TNC 410
340490 280476 286140 286060
1, Pecking – þþ þþ
2, Tapping – þþ þþ
3, Slot milling – þþ þþ
4, Pocket milling – þþ þþ
5, Circular pocket – þþ þþ
6, Rough out (SL I) – þþ þþ
7, Datum shift – þþ þþ
8, Mirror image – þþ þþ
9, Dwell time – þþ þþ
10, Rotation – þþ þþ
11, Scaling – þþ þþ
12, Program call – þþ þþ
13, Spindle orientation – þþ þþ
14, Contour definition – þþ þþ
15, Pilot drilling (SL I) – þþ þþ
16, Contour milling (SL I) – þþ þþ
18, Thread cutting – þþ xx
19, Working plane – þþ xx
20, Contour data – þþ xx
21, Pilot drilling – þþ xx
22, Rough-out Q208
Q401
þ
þ
–
–
x
x
x
x
23, Floor finishing – þþ xx
