2.2 Connecting the programming station
Working with the HEIDENHAIN basic
PLC program
After you have started the programming station, the most important
programming station functions for machine tool operation become
available.
The vertical soft-key row includes important soft keys for machine tool
operation such as NC start, NC stop, positive or negative traverse
direction of axis.
Use the mouse in combination with the vertical soft-key row to
simulate various machine functions of the basic PLC program:
Soft key Keys
M NC start
NC stop
Move axes in positive and negative
direction
Exit the programming station
S Spindle ON
Spindle OFF
Incremental spindle jog M3
Incremental spindle jog M4
Oriented spindle stop M19
T Acknowledge tool change
Clamp/release tool
DIAGNOSIS Show PLC error table
Diagnostic functions
Status functions
Documentation for M functions
