Translation of the original instructions / Small animal clipper 19
Malfunction Cause Rectication
The control light of
the charging station
in not on
Charging station is not
connected to the power
supply
Connect the charging station to
the power supply
Charging station is faulty Have charging station inspected
(S)
When the battery is
at the light of the
charging station
does not change
from green to red
Contacts of battery and/
or charging station are
dirty
Clean contacts
Faulty battery Replace battery
Battery exhausted Place the battery in the charging
station for at least 20 minutes.
Replace the battery if the char-
ging process fails to start.
Contacts of the charging
station are deformed
Have the charging station re-
paired (S)
8 Spare parts
See illustration spare parts at the end of this instruction manual.
WARNING!
Faulty spare parts may cause damages, malfunctions or total loss and may
reduce security. Therefore:
X
Only use original spare parts from the manufacturer. Purchase the spare
partsattheofcialdistributorordirectlyatthemanufacturer.
X
If using no original spare parts all warranty and service claims are expi-
ring.
Pos. No. Description Quantity
1 Top housing shell, complete 1x
2 Bottom housing shell, complete 1x
3 Battery 1x
4 Motor complete 1x
5 Front motor holder 1x
6 Rear motor holder 1x
7 PCB clipper 1x
8 Turning lever 1x
9 Rubber tap 1x
10 Seal 1x
11 Kombitorx KA30x16 PT screw 12x
12 Kombitorx KA30x8 PT-screw 1x
22 Blade support 1x
23 Bladeinterlock 1x
24 Clipping pressure spring 1x
25 Blade guide 1x
