11 Parameter description
Positioner DC 6-06 75
No. Name Meaning
1700 ActuatorTestSetpoint
Level: 2
Range: 0..100 %
Page(s): 54
Setpoint for
the control path in test mode for setting and
testing the actuator
1701 ActuatorTstAmplitude
Level: 2
Range: 0..100 %
Page(s): 54
Am
plitude of the control path step generator in test
mode for setting and testing the actuator
1702 ActuatorTstFrequency
Level: 2
Range: 0..100 %
Page(s): 54
Frequency
setting for test mode for setting and testing
the actuator
1800 Level
Level: 1
Range: 1..7
Page(s): 13
User level
Maxim
um level of the dongle or hand programmer,
can be reduced
1876 ValueStep for hand programmers only
Level: 2
Range: 0..65535
Increment for value changes
1900 FeedbackAdjustTime
Level: 6
Range: 0..100 s
Page(s): 50
Position hold
time with the auto adjust
1905 ServoCorrFactor
Level: 6
Range: 0..400 %
Page(s): 52
Correction factor of the PID value for servo loop
1906 ServoCorrRange
Level: 6
Range: 0..50 %
Page(s): 52
Position range for correcti
on factor
1911 ServoGain
Level: 6
Range: 0..100 %
Page(s): 11, 52
Proportio
nal factor for the servo loop
1912 ServoStability
Level: 6
Range: 0..100 %
Page(s): 52
Integral factor for the servo loop
1913 ServoDerivative
Level: 6
Range: 0..100 %
Page(s): 52
Differential f
actor for the servo loop
