Heinzmann PANDAROS DC 6-06 User Manual

11 Parameter description
76 Positioner DC 6-06
No. Name Meaning
1914 ServoAcceleration
Level: 6
Range: 0..100 %
Page(s): 52
DD factor for
the servo loop
1915 ServoCurrentOffDelay
Level: 6
Range: 0..100 s
Page(s): 22
Delay
time for the start of the current shutoff of the
actuator when no more setpoints are selected or a stop
request is present
1916 ServoCurrentRedDelay
Level: 6
Range: 0..100 s
Page(s): 53
Delay
time for the start of current reduction of the
actuator
1917 ServoCurrentMax
Level: 6
Range: 0..12.5 A
Page(s): 53
Maxim
um current for the actuator (during motion)
1918 ServoCurrentRed
Level: 6
Range: 0..12.5 A
Page(s): 53
Reduced current for the static state of the actuator
1919 ServoCurrentAdjust
Level: 6
Range: 0..12.5 A
Page(s): 50
Current durin
g automatic adjustment of the actuator
1920 ServoCurrentPC
Level: 6
Range: -12.5..12.5 A
Page(s):
Current input from the PC
1950 FeedbackRef_0%
Level: 4
Range: 0..65535
Page(s): 49
0 % reference value for the
feedback
(RESET)
1951 FeedbackRef_100%
Level: 4
Range: 0..65535
Page(s): 49
100 %
reference value for the feedback
(RESET)
1952 FeedbackErrLow
Level: 4
Range: 0..65535
Page(s): 51, 65
Lower error value for the feedback
1953 FeedbackErrHigh
Level: 4
Range: 0..65535
Page(s): 51, 65
Upper error value for the feedback
