11 Parameter description
Positioner DC 6-06 81
3195 SExceptionNumber
to
3198
Level: 1
Range: 0..FFFF Hex
Page(s): 28, 70
Identifiers for the internal software error
3094
3500 FuelSetpPWMIn1
Level: 1
Range: 0..100 %
Page(s): 26, 35
Current value of PWM in
put 1 for setpoint selection
3501 FuelSetpFrequencyIn1
Level: 1
Range: 0..1000 Hz
Page(s): 26, 35
Current frequency
at PWM input 1 for setpoint
selection
3504 FuelSetpPWMIn3
Level: 1
Range: 0..100 %
Page(s): 26
Current value of PWM in
put 3 for setpoint selection
3505 FuelSetpFrequencyIn3
Level: 1
Range: 0..1000 Hz
Page(s): 26
Current frequency
at PWM input 3 for setpoint
selection
3510 AnaStop_Percent
Level: 1
Range: 0..100 %
Page(s): 32
Scaled value of the analog
ue input for the stop request
3511 AnaStop_Value
Level: 1
Range: 0..5 V
or 0..22 mA
Page(s): 26, 32
Unscaled val
ue of the analogue input for the stop
request
3530 FuelSetpAna_Percent
Level: 1
Range: 0..100 %
Page(s): 32
Scaled value of the analog
ue input for the setpoint
selection
3531 FuelSetpAna_Value
Level: 1
Range: 0..5 V
or 0..22 mA
Page(s): 25, 32
Unscaled val
ue of the analogue input for the setpoint
selection
3600 PowerSupply
Level: 1
Range: 0..55 V
Page(s): 28
Current value of the filtered suppl
y voltage
3601 LowPowerEnabled
Level: 1
Range: 0..1
Page(s): 29
1: Undervolta
ge is supported by the control unit and is
requested by parameter 5600 LowPowerEnable
