Heinzmann PANDAROS DC 6-06 User Manual

11 Parameter description
82 Positioner DC 6-06
3602 PowerSupplyRaw
Level: 1
Range: 0..55 V
Page(s): 28
Current measured value of
supply voltage x:
3603 5V_Ref
Level: 1
Range: 0..10 V
Page(s): 67
Current value of the 5V reference voltage
3800 Em
ergencyAlarm
Level: 1
Range: 0/1
Page(s): 59, 63
Display
of the emergency alarm
3801 CommonAlarm
Level: 1
Range: 0/1
Page(s): 25, 26, 37, 59
Display
of the common alarm
3802 SystemStopRequest
Level: 1
Range: 0/1
Page(s): 22
Shows that th
e system is stopped by an internally or
externally present stop (1 = stop request is active)
3803 SystemStopped
Level: 1
Range: 0/1
Page(s): 22
1 = shows that the sy
stem is stopped
3830 Phase
Level: 1
Range: 0..9
Page(s): 22
Current phase of the s
ystem
0: Waiting for start
4: Setpoint selection active
8: Auto adjust
9: Positioner operation
3840 HardwareVersion
Level: 1
Range: 00.00..99.99
Page(s): 56
Version number of the con
trol unit hardware
3841 AddHardwareVersion
Level: 1
Range: 00.00..99.99
Page(s): 56
Additional ve
rsion number of the control unit hardware
3842 SoftwareVersion
Level: 1
Range: 00.0.00...64.9.99
or 0000.00.00...6552.99.99
Page(s): 8, 56
Version number of the software (fir
mware)
2 digits customer number
1 digit variant
2 digits change index
