Helios easyControls 3.0 KWL 200 W User Manual

Central ventilation unit – KWL 200/300 W/W ET
Installation and Operating Instructions
ENEN
9
3.4 Dimensions
300
21
658
125
65
Kugelsiphon
130
110
144 144
361
85 85
600
Zuluft
Aussenluft
Fortluft
Abluft
Dimensions in mm
Fig. 3
KWL 200/300 W/W ET R
300
125
21
658
65
Kugelsiphon
85 144 144 85
600
361
110
130
Abluft
Aussenluft
Zuluft
Fortluft
Dimensions in mm
Fig. 4
KWL 200/300 W/W ET L
Extract air
Exhaust air
Supply air
Intake air
Ball siphon
Intake air
Exhaust air
Supply air Extract air
Ball siphon
