Central ventilation unit – KWL 200/300 W/W ET
Installation and Operating Instructions
ENEN
21
6.1 Initial commissioning
The unit must be properly connected or linked to the mains power supply for the initial commissioning. The commissio-
ning assistant can then run via the local web server or optionally via the control element KWL-BE Touch (accessories).
• Initial commissioning via local web server
– Set up local web server, see chapter 7.1.1 „Local web server“, page 28.
– Run commissioning assistant, see chapter 6.2 „Run commissioning assistant“.
• Initial commissioning via control element KWL-BE Touch (accessories))
Installation and commissioning see Installation and Operating Instructions KWL-BE Touch.
ⓘ
The unit cannot operate without successfully completing the initial commissioning!
6.2 Run commissioning assistant
ⓘ
In order to run the commissioning assistant, the local web server of the KWL
®
unit must be connected to a
mobile end device (see chapter 7.1.1 „Local web server“, page 28).
1. Establish connection of the local web server (KWL
®
unit) to a mobile end device.
> The commissioning assistant starts automatically for the initial commissioning.
Otherwise, the unit must be reset to factory settings to start the commissioning assistant again.
2. Configure settings for language, time and date and click “Next”.
> The settings for access rights are displayed.
3. Configure settings for access rights and click “Next”.
> The settings for unit configuration are displayed.
CHAPTER 6
COMMISSIONING
Fig. 29
Fig. 30
ⓘ
Master code: 0000 (pre-set)
ⓘ
Function only available for control element KWL-BE Touch.
