HellermannTyton AT2000 CPK - BMK Tool Mount CPK; Hole Pattern of BMK Base Plate CPK; BMK Holder

USDE
Automation Instructions CPK • 10-2015 •106-29009
Technical data
26
7.3.1 BMK tool mount CPK
124,5
158,5
9,3
63 65
149,5
40
22
6
7.3.2 Hole pattern of BMK base plate CPK
260
20
5,3
20
260
20 20
7.3.3 BMK holder
785
549,5
60
10020
12
